To create this jewel, we have combined the knowledge of our engineers and the most expert testers, together with feedback from pro cyclists. The result is a new wheelset for racing bikes with the magic ratio of features: lightweight construction, unmatched reactivity and superior handling.
We have taken H.U.L.C. molding technology and C-LUX finish to the next level to make Hyperon Ultras easy on the eye and light on the scales.
With the aim of enhancing cyclists’ riding experience and performance, we have achieved unmatched reactivity with the new Head-2-Bay system, created to ensure high precision head-to-bay coupling, to which we have fitted super-smooth CULT bearings and a new lighter N3W freewheel body.
For superior handling, we relied on historic Campagnolo knowhow and also applied the famous Aero-MoMag technology to the Hyperon Ultra wheels, ensuring benefits in terms of aerodynamics and even better looks. The rims feature the tried and tested 2-Way Fit technology with no holes on the upper bridge. Their special single-joint construction guarantees and further increases wheelset stiffness.
With an inner width of 21mm and rim profile of 37mm, Hyperon Ultra is a wheel that adapts to the needs of even the most demanding cyclist while enhancing the looks of any bike.
HYPERON ULTRA DB: The magic ratio of performance.
SPECIFICATIONS
SPOKES
- 21 circular-section slim steel spokes on the front in a two-cross pattern
- 24 circular-section slim steel spokes on the rear in a two-cross pattern
VERSIONS AND WEIGHTS
- Campagnolo N3W™ body
- HG11 body
- XDR body
- Available for 2-Way Fit: 1.240 g
COMPATIBILITY
- Campagnolo 10/11/12 speed cassette
- Shimano/SRAM 10/11 speed cassette
- SRAM 12 speed cassette
HUB
- Monolithic hub in Black Aluminum
- CULT bearings
- Hub edges: 100 mm front, 142 mm rear
- Axle material: aluminum
RIM
- Profile height: 37 mm
- Material used for rim: Carbon
- Rim section (height/width): 37/ 26.7 mm
- Internal rim width: 21 mm
- Water Transfer Graphics
TYRES
- Tubular
ASSEMBLY
The Ruota Hyperon Ultra™ Disc Brake wheel is entirely hand-assembled by a specialised Campagnolo® technician and is 100% checked by electronic instrumentation. This procedure ensures that every single Campagnolo® wheel offers maximum performance and reliability
